Facet 476459 Silver Top Competition Cylindrical Fuel Pump -
An industry standard for over 60 years, these lightweight compact pumps can be found in almost every conceivable application. With output ranges up to 170.3 liters/hour, .68 bar, these pumps will provide high-performance output for everything from racing cars to heavy duty agricultural and construction machinery. E10 E85 Compatible.
Specification:- Fast Road
Pump:- 476459E
Voltage:- 12v
Earth:- Neg
Pressure (Psi):- 6.0-7.0
Flow:- US Gallons/Hr 35
Dry Prime Height in Mtrs:- 0.6
Thread Size:- 1/8th nptf
Operating Temperature:- -40 to +180 F (all Models)
Average Run Time or MTBF:- 6000 hrs
Length:-140mm
Diameter:- 54mm
Weight:-0.7kg
Additional items:
Union FPA9001= 1/8th -6mm or
Union FPA9011 = 1/8th- 8mm
Fuel Hose 6mm ID = ref. 2134.0400
Fuel Hose 8mmID= ref. 2134.0600
Braided Fuel Hose 6mm ID = ref. BRAIDED01
Braided Fuel Hose 8mmID = ref. BRAIDED02
Fuel Filter Plastic 6mm-8mm : ref. SL-GFE7004
Please Note:- Designed and manufactured to automotive specification and not recommended for the maintenance of flight
Applications:- Motorsport, Marine
